5-5
5 Sysmac Studio Settings
f
or the EtherNet/IP
Unit
CJ-series EtherNet/IP Unit
s Operation Manual for NJ-series CPU Unit (W495)
5-3 Link Settings Display
5
5-3
Link Settings Displa
y
Setting
Description
Default
LINK settings
Set the baud rate f
or the EtherNet/IP Unit.
•
Aut
o
•
10 Mbps Half Duplex
•
10 Mbps Full Duplex
•
100 Mbps Half Duplex
•
100 Mbps Full Duplex
Aut
o
116
118
