Omron CJ1W-EIP21 User Manual

13 Troubleshooting
13-2
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
13-1 Checking Status with the Network
Configurator
Connect the Network Configurator online, select the device to be checked, right-click to display the pop-
up menu, and select Monitor.
The Monitor Device Dialog Box will be displayed.
Additional Information
If a communications error occurs during monitoring, the dialog box will continue to show the last
information that was collected. To start monitoring again, close the Monitor Device Dialog Box,
and then open the dialog box again.
13-1-1 The Network Configurator's Device Monitor Function
