11 SNMP Agent
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
11-2 Procedure to Use the SNMP Agent
11
11-2-1 Procedures
11-2 Procedure to Use the SNMP Agent
1 Make the basic settings.
Refer to 1-5 EtherNet/IP Communications Procedures for the flow of basic operations.
2 Make the following settings in the Special Unit Setup in the Controller Configurations and Setup
of the Sysmac Studio and then set the following on the SNMP Settings Display or SNMP Trap
Settings Display.
• SNMP Service
• Recognition 1
• Recognition 2
3 Select Transfer to Controller from the Controller Menu and click the Yes Button. The Ether-
Net/IP Unit settings are transferred to the CPU Unit.
The following EtherNet/IP Unit settings are made from the Sysmac Studio to use the SNMP agent.
11-2-1 Procedures
11-2-2 Settings Required for the SNMP Agent
Tab page Setting Setting conditions Reference
SNMP Settings SNMP service Required. page 5-9
Port No. Specified by user.
Note Required to change from the default
value of 161.
Address, location Specified by user.
Send a recognition trap Specified by user.
Select this check box to send a recognition
trap if there is access from an SNMP man-
ager that is not specified (Access other than
Recognition 1 and 2).
Recognition 1 and Recognition
2
Specified by user.
Make these settings to permit access by only
certain SNMP managers.
page 5-10
IP address
Host name
Community name
SNMP Trap Set-
tings
SNMP trap Required. page 5-11
Port No. Specified by user.
Note Required to change from the default
value of 162.
Trap 1 and trap 2 page 5-12
IP address Required.
Set an IP address or a host name as the
SNMP trap destination.
Host name
Community name Specified by user.
Version Required.
Set the version of the SNMP manager.
