Related Manuals
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
Related Manuals
The following manuals are related to the NJ-series Controllers. Use these manuals for reference.
Manual name Cat. No. Model numbers Application Description
NJ-series CPU Unit
Hardware User’s Manual
W500 NJ501-@@@@
NJ301-@@@@
Learning the basic specifi-
cations of the NJ-series
CPU Units, including intro-
ductory information,
designing, installation, and
maintenance. Mainly hard-
ware information is pro-
vided.
An introduction to the entire NJ-series system is
provided along with the following information on
the CPU Unit.
• Features and system configuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspection
Use this manual together with the NJ-series
CPU Unit Software User’s Manual (Cat. No.
W501).
NJ-series CPU Unit Soft-
ware User’s Manual
W501 NJ501-@@@@
NJ301-@@@@
Learning how to program
and set up an NJ-series
CPU Unit. Mainly software
information is provided.
The following information is provided on a Con-
troller built with an NJ501 CPU Unit.
• CPU Unit operation
• CPU Unit features
• Initial settings
• Programming based on IEC 61131-3 lan-
guage specifications
Use this manual together with the NJ-series
CPU Unit Hardware User’s Manual (Cat. No.
W500).
NJ-series CPU Unit Built-
in EtherNet/IP
TM
Port
User’s Manual
W506 NJ501-@@@@
NJ301-@@@@
Using the built-in Ether-
Net/IP port on an NJ-series
CPU Unit.
Information on the built-in EtherNet/IP port is
provided. Information is provided on the basic
setup, tag data links, and other features.
Use this manual together with the NJ-series
CPU Unit Hardware User’s Manual (Cat. No.
W500) and NJ-series CPU Unit Software User’s
Manual (Cat. No. W501).
Sysmac Studio Version 1
Operation Manual
W504 SYSMAC-
SE2@@@
Learning about the operat-
ing procedures and func-
tions of the Sysmac Studio.
Describes the operating procedures of the Sys-
mac Studio.
EtherNet/IP
TM
Units
Operation Manual
W465 CS1W-EIP21
CJ1W-EIP21
CJ2H-CPU6@-EIP
CJ2M-CPU3@
Learning how to use an
EtherNet/IP Unit
Information on using an EtherNet/IP Unit that is
connected to a CS/CJ-series CPU Unit is pro-
vided.
Information is provided on the basic setup, tag
data links, and FINS communications.
Refer to the Communications Commands Refer-
ence Manual (Cat. No. W342) for details on
FINS commands that can be sent to CS/CJ-
series CPU Units when using the FINS commu-
nications service.
Refer to the Ethernet Units Operation Manual
Construction of Applications (Cat. No. W421) for
details on constructing host applications that
use FINS communications.
CJ-series EtherNet/IP
TM
Units Operation Manual
for NJ-series CPU Unit
W495
(this
manual)
CJ1W-EIP21 Learning how to use the
EtherNet/IP Unit
Information on using an EtherNet/IP Unit that is
connected to an NJ-series CPU Unit is provided.
Information is provided on the basic setup, tag
data links, and other features.
Use this manual together with the NJ-series
CPU Unit Hardware User’s Manual (Cat. No.
W500) and NJ-series CPU Unit Software User’s
Manual (Cat. No. W501).
