9-5
9 FTP Server
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
9-3 Using the FTP Server
Function
9
9-3-1 Procedure
9-3 Using the FTP Server Function
1
Make the basic settings.
Refer to 1-5-1 Basic Operation for basic operations.
2
Set up the FTP server on the Sysmac Studio. (Refer to 5-4 FTP Settings Display.)
3
Select EtherNet/IP Unit Settings under Configuration − Controller Setup on the Sysmac
Studio. Make the following settings on the FTP Settings Display.
• FTP server
• Port number
• Login name
• Password
4
Place the CPU Unit online and transfer the settings to the Controller.
5
Insert the SD Memory Card into the CPU Unit.
6
Connect to the EtherNet/IP Unit from an FTP client.
7
Input the FTP login name and password that you set in the EtherNet/IP Unit Settings to log in to
the EtherNet/IP Unit.
8
After you are logged in, you can use the ftp commands, such as cd (Change Directory) and get
(Obtain File) for the MEMCARD1 directory in the SD Memory Card in the Controller.
9
Close the connection.
Make the following settings for the unit setup when the FTP server function is used.
* Settings are not required if the FTP server is not used.
Make the settings in the FTP Settings Dialog Box if the FTP server is used. Refer to 5-4 FTP Set-
tings Display for information on the FTP Settings Dialog Box.
9-3-1 Procedure
9-3-2 List of Settings Required for the FTP Server Function
EtherNet/IP Unit
Settings Tab Page on
Sysmac Studio
Setting Setting conditions Reference
FTP FTP server Required page 5-6
Port No.
Optional
*
Note Required when
changing the default
value of 21.
Login name
Required
*
Password
Required
*
To Next Page
