Omron CJ1W-EIP21 User Manual

13-27
13 Troubleshooting
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
13-4 Error Log
13
13-4-2 Error Log Error Codes
Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504) for the functions and oper-
ating procedures for the Controller event logs.
13-4-2 Error Log Error Codes
Error
code
(hex)
Error
Detail code Saved in
non-volatile
memory
First byte Second byte
0001 CPU Unit watchdog timer error 00 hex 00 hex Yes
0002 CPU Unit service monitoring error Monitoring time (ms) Yes
0006 Other CPU error Bit D11: Unit not in Registered I/O Tables
(Other bits are reserved for system use.)
Ye s
000E I/O bus error 00 hex 00 hex Yes
000F CPU Unit initialization error 00 hex 00 hex Yes
0011 Event timed out MRC (main command) SRC (subcommand) Yes
0012 CPU Unit memory error 01 hex: Read error
02 hex: Write error
03 hex: Routing tables
05 hex: CPU Bus Unit
Area (CIO or DM)
Ye s
0015 CPU Unit fatal error 00 hex 00 hex Yes
0017 Tag database error 00 hex 00 hex Yes
0103 Resend count exceeded (send failed) CIP Frame:
FFFF
No
0105 Node address setting error (send failed) No
0107 Remote node not in network (send
failed)
No
0108 No Unit with specified unit address (send
failed)
No
010B CPU Unit error (send failed) No
010D Destination address not in routing tables
(send failed)
No
010E Not registered in routing tables (send
failed)
No
010F Routing table error (send failed) No
0110 Too many relay points (send failed) No
0111 Command too long (send failed) No
0112 Header error (send failed) No
0117 Internal buffers full; packet discarded No
0118 Illegal packet discarded No
0119 Local node busy (send failed) No
0120 Unexpected routing error No
0122 Service not supported in current mode;
packet discarded
No
0123 Internal send buffer full; packet dis-
carded
No
0124 Maximum frame size exceeded; routing
failed
No
0125 Response timeout; packet discarded No
020F Communications controller error 00 hex 01 hex Yes
0211 IP address duplication Port number (always 02) Lower eight bits of IP
address
Ye s
