7-61
7 Tag Data Link Functions
CJ-series EtherNet/IP Units Operation Manual for NJ-series CPU Unit (W495)
7-2 Setting Tag Data Links
7
7-2-13 Clearing the Device Parameters
You can clear the tag data link parameters that are saved in the EtherNet/IP Unit on the EtherNet/IP
network to return them to their default settings. The following procedure shows how to clear the tag data
link parameters. For details on how to connect to the network from the Network Configurator, refer to 7-
2-8 Connecting the Network Configurator to the Network.
1
Connect the Network Configurator online.
2
Select the icon of the EtherNet/IP Unit from which you want to clear the device parameters. In
the following example, 2 nodes are selected: 192.168.250.1 and 192.168.250.2. To select multi-
ple nodes, press and hold the Shift Key while you select additional icons.
3
Select Device - Reset. You can also right-click the icon and select Reset from the popup menu.
4
The following dialog box is displayed.
7-2-13 Clearing the Device Parameters
To Next Page
