Parameter
No.
Data Description
Com-
mu-
nica-
tions
func-
tion
Reference item Page
E01 to E05,
E98, E99
0 CF1:
Multi-step frequency setting
binary 1
E
Multi-step speed operation
function
page
5-57
1 CF2:
Multi-step frequency setting
binary 2
E
2 CF3:
Multi-step frequency setting
binary 3
E
3 CF4:
Multi-step frequency setting
binary 4
E
4 RT1:
Select ACC/DEC time (2
steps)
E
2-step acceleration/deceler-
ation function
2-step acceleration/deceler-
ation
page
5-43
page
5-66
5 RT2:
Select ACC/DEC time (4
steps)
E
6 STP: 3-wire stop: NC contact - 3-wire input function
page
5-56
7 FRS: Free-run stop O Free-run stop
page
7-60
8 RS: Reset O
Reset
Reset (RS)
page
5-49
page
5-66
9 EXT: External trip: NC contact - External trip
page
7-87
10 JG: Jogging O Jogging
page
5-60
12 SET: Set 2nd control O 2nd control function
page
5-52
13 DB:
External DC injection brak-
ing
E Direct current braking
page
7-63
14 TRQ1: Torque limit switching 1 E Torque limit function
page
6-81
15 CS: Commercial switch E
Commercial switching
page
7-141
16 SW60: Commercial switch (60Hz) E
17 UP:
UP/DWN function accelerat-
ed
-
Remote operation function
page
7-119
18 DWN:
UP/DWN function decelerat-
ed
-
19
SFT: Soft lock O Soft lock
page
7-74
20 PID: PID enabled/disabled E
PID function
page
7-123
21 IVS:
Switch normal/inverse oper-
ation
E
22 IL: Interlock -
Restart after Momentary
Power Failure
page
7-155
7 Other Functions
7-27
M1 Series Standard Type User's Manual (I669)
7-2 Multifunction Input/Output Functions List
7
7-2-1 Multifunction Input Selection
