7-9-13
PID Function
PID control detects the status (control amount) of the object to be controlled by a sensor, etc., and
compares it with the target value (such as the temperature command). If there is a deviation during
this time, operation is performed to set the deviation to zero. It is a closed loop control method that
matches the control amount (feedback value) with the target value.
It is possible to perform process controls such as the flow rate control, pressure control, temperature
control, etc., and speed controls such as the dancer control.
If PID control is enabled (PID Control Function Selection (J01) = 1 to 5), the frequency setting block
switches to PID control block.
The PID function is disabled in the case of the torque control (refer to 6-6 T
orque Control on page
6-31) and the position control (refer to
6-7 Position Control on page 6-36).
Parameter
No.
Function name Data
Default
data
Unit
E119
PID Control Feedback Selec-
tion
0: Analog input terminals (AI1, AI2
(AII function), AI2 (AIV function))
2: Modbus communication
3: Pulse train frequency
0 -
E120
PID Control PID Output Varia-
ble Range for Process Control
0.0: Function disabled
0.1 to 100.0: V
ariable range based on
target value
0 -
E121
PID Control PID Feedforward
Selection for Process Control
0: Disable
1: Analog input terminals AI1, AI2
(AII), AI2 (AIV)
0
-
C59
Input Terminal [AI1] Analog In-
put Adjustment Maximum Scale
-999.00 to 0.00 to 9,990.00 100 -
C60
Input Terminal [AI1] Analog In-
put Adjustment Minimum Scale
-999.00 to 0.00 to 9,990.00 0 -
C65
Input Terminal [AI2] Analog In-
put Adjustment Maximum Scale
(AII)
-999.00 to 0.00 to 9990.00 100 -
C66
Input Terminal [AI2] Analog In-
put Adjustment Minimum Scale
(AII)
-999.00 to 0.00 to 9990.00 0 -
C71
Input Terminal [AI2] Analog In-
put Adjustment Maximum Scale
(AIV)
-999.00 to 0.00 to 9990.00 100 -
C72
Input Terminal [AI2] Analog In-
put Adjustment Minimum Scale
(AIV)
-999.00 to 0.00 to 9990.00 0 -
J01 PID Control Function Selection
0: Disable
1: Process normal operation
2: Process (inverse operation)
3: Speed control (Dancer)
4: Process (normal operation, oppo-
site operation available)
5: Process (inverse operation, oppo-
site operation available)
0 -
7 Other Functions
7-123
M1 Series Standard Type User's Manual (I669)
7-9 Other Operation Functions
7
7-9-13 PID Function
