Omron M1 Series User Manual

Parameter
No.
Function name Data
Default
data
Unit
F14
Power Interruption Re-
start Mode Selection
0: Immediately trip (Free run stop)
1: Trip after a recovery from power failure (Free
run stop)
2: Trip after decelerate-to-stop
3: Continue to run
4: Restart at the frequency selected by (E152)
6: Decelerate-to-stop (w/o trip)
1
-
E01 to E05,
E98, E99
Input Terminal [DI1] to
[DI7] Function Selec-
tion
26: STM (Enable auto search for idling motor
speed at starting)
22: IL (Interlock)
- -
H09
Motor Starting Mode
Auto Search Function
Selection
0: Disable
1: Enable only at restart after momentary power
failure
2: Enable at normal start and restart after mo-
mentary power failure
0 -
d67
Motor Starting Mode
Auto Search in Speed
Sensor less Vector
Control
H16
Allowable Time for
Power Interruption Re-
start
0.0 to 30.0
999: Auto judgment by the inverter
999
s
H13
Power Interruption Re-
start Wait Time
0.1 to 100.0 0.5
s
H14
Deceleration Setting
During Current Limit
for Restart Mode after
Power Interruption
0.00: Selected deceleration time
0.01 to 100.00
999: According to current limiter
999 Hz/s
H15
Continuous Running
Voltage Level
200 to 300: (200 V class series)
400 to 600: (400 V class series)
235 V
H49
Auto Search Delay
Time 1 for Starting
Characteristic
0.0 to 10.0 0.0 s
H46
Auto Search Delay
Time 2 for Starting
Mode
0.1 to 100.0 1.0 s
H92
Continuous Running at
the Momentary Power
Failure P Proportional
Gain
0.000 to 10.000
999: Auto
999
time
H93
Continuous Running at
the Momentary Power
Failure Integral Time
0.010 to 10.000
999: Auto
999 s
E152
Starting Frequency
Selection at Frequency
Pull-in Restart
0: Frequency at which the power failure occur-
red
1: Maximum output frequency
2: Reference frequency
3: Starting frequency
3
-
7 Other Functions
7-50
M1 Series Standard Type User's Manual (I669)
