6-4SectionMemory Initialization
114
Reference: S The
NT21 also allows the alarm history record data
to be initialized by control
-
ling the PT Status Control Area from the host. For details, refer to 2-2-1 PT
Status Control Area in the Reference Manual.
S If
the optional battery is not installed, the alarm history record data will be initial
-
ized when the PT’s power is turned OFF.
Initialize
the alarm history record data by following the menu operations from the
Maintenance Mode Menu as shown below.
Select Memory Init..
Select Alarm History.
Select Y
es.
The alarm history record data is initialized.
During
initialization, the message Initializing
is displayed.
If
No is selected, the NT21 returns to the MEMOR
Y INIT
. MENU screen without
initializing the alarm history record data.
On
completion of alarm history record data initialization, the message Finished
is displayed and the NT21 returns to the MEMORY INIT. MENU screen.
6-4-4 Initializing the Memory Tables
It
is possible to initialize the numeral memory table and
character string memory
table in the NT21.
When
these tables are initialized, the values are returned to those set
by the NT
Support Tool (they are not cleared).
When
the memory tables are initialized, they are returned to their initial
values
regardless of the setting made for the resume function (page 140).
If
ON
is set for the Resume Function memory switch, the initial values set with
the NT Support T
ool will not be recorded in the memory tables unless they are
initialized.
To Next Page
