Appendix A
Specifications
General Specifications
Item Specification
Rated power supply voltage 24 VDC
Allowable power supply voltage range 20.4 VDC to 27.6 VDC (24 VDC –15% to +15%)
Allowable power interruption time No regulation
Power consumption 7 W max.
Ambient temperature
Operating: 0 to +50_C
Storage: –20 to +70_C
Operating ambient humidity
35% to 85% humidity at 0 to 40_C (with no condensation)
35% to 55% humidity at 40 to 50_C (with no condensation)
Operating environment No corrosive gases
Noise resistance
Conforms to IEC 61000-4-4.
2,000 V (power supply line)
Vibration resistance (operating)
10 to 57 Hz with 0.075 mm amplitude and 57 to 150 Hz with 9.8 m/s
2
acceleration for 60 minutes in each of X, Y, Z directions
Shock resistance (operating) 147 m/s
2
, 3 times in each of X, Y, and Z directions
Dimensions
190 (W)
1
10 (H) 53.5 (D) mm
(With Expansion Unit mounted: 190 (W)
1
10 (H) 73.5 (D) mm)
Panel cutout dimensions
178.5
×
100.5 mm
+0.5
0
+0.5
0
Panel thickness range: 1.6 to 4.8 mm
Weight 0.6 kg max.
Enclosure ratings Front panel: Equivalent to IP65F (NEMA4)*
Grounding D-type grounding (Ground to 100 Ω or less)
International standards UL, cULus, EC directives, C-Tick Class 1 Division 2
* The NT21 may not be used at a location where it is exposed to splashing oil for a long period.
