Pfaff 3307-1 SERIES User Manual

Adjustment
13 - 31
-0
1
6
13.31 Setting the angle for the end knotting (only on subclasses -1/.. and -4/..)
● Switch on the machine.
● Switch on the end knotting function, see Chapter 11 Input
● By turning the balance wheel 1 to "36" set parameter "506" (engaging position).
● By turning the balance wheel 1 to "52" set parameter "507" (disengaging position).
● Carry out ten sewing operations. Select parameter "604" and interpret the values for the
engaging and disengaging position of the last ten sewing operations.
For uneven values (engaging position) the value should be "70".
For even values (disengaging position) the value should be "90".
● Change parameters "506" and "507" accordingly, a deviation of +/- 1 is permitted.
● Switch off the machine.
Fig. 13 - 29
1
