Setting Item Default Value Setting Details
HDMI 4K Signal
Fomat
Standard When an AV component such as a TV or player
that supports HDMI 4K is connected to this unit,
you can switch the 4K signal format that is input/
output by this unit.
"Standard": When the AV component connected to
this unit supports the standard 4K signal format (4K
60p 4:2:0 8bit).
"Enhanced": When the AV component connected
to this unit and the HDMI cable supports the high-
denition 4K signal formats (4K 60p 4:4:4, 4:2:2
and 4K 60p 4:2:0 10bit).
Settings and the corresponding resolutions
Enhanced Standard
4K (3840×2160p)
24/25/30 Hz
4KSMPTE(4096×2160p)
24/25/30 Hz
RGB/
YCbCr4:4:4
8 bit
10/12 bit
YCbCr4:2:2 12 bit
4K (3840×2160p)
50/60 Hz
4K SMPTE(4096×2160p)
50/60 Hz
RGB/
YCbCr4:4:4
8 bit
YCbCr4:2:2 12 bit
YCbCr4:2:0
8 bit
10/12 bit
• When setting to "Enhanced", use Premium
High Speed HDMI Cable or Premium High
Speed HDMI Cable with Ethernet that have the
"PREMIUM Certied Cable" label attached to the
packaging.
• There may be some image disruption depending
on the connected component and the HDMI
cable. If this occurs, switch to "Standard".
Zone 2 HDMI Not Use Make the setting when you output to the Zone 2 TV
connected to the HDMI OUT ZONE 2 jack.
"Use": Enable this function
"Not Use": Disable this function
• When video and audio via HDMI input are output
to ZONE 2, set to "Use".
Setting Item Default Value Setting Details
OSD Language English Select the on-screen display language from the
following.
(North American models) English, German, French,
Spanish, Italian, Dutch, Swedish
(European models) English, German, French,
Spanish, Italian, Dutch, Swedish, Russian, Chinese
Impose OSD On Set whether or not to display information such as
volume adjustment or switching of input on the TV
screen.
"On": OSD is displayed on the TV.
"Off": OSD is not displayed on the TV.
• OSD may not be displayed depending on the
input signal even if "On" is selected. In this case,
change the resolution of the connected device.
Screen Saver 3 minutes Set the time to start the screen saver.
Select a value from "3 minutes", "5 minutes",
"10 minutes" and "Off".
 HDMI Input
Change input assignment between the input selectors and HDMI IN jacks.
Setting Item Default Value Setting Details
BD/DVD HDMI 2
(HDCP 2.3)
"HDMI 1 (HDCP 2.3)" to "HDMI 4 (HDCP 2.3)":
Assign a desired HDMI IN jack to the BD/DVD input
selector. If you do not assign a jack, select "---". To
select an HDMI IN jack already assigned to another
input selector, change its setting to "---" rst.
GAME HDMI 1
(HDCP 2.3)
"HDMI 1 (HDCP 2.3)" to "HDMI 4 (HDCP 2.3)":
Assign a desired HDMI IN jack to the GAME input
selector. If you do not assign a jack, select "---". To
select an HDMI IN jack already assigned to another
input selector, change its setting to "---" rst.
