Speakers
Connecting speakers
You can select the layout of speakers to be installed from various patterns when using this unit. Use the following ow chart to select the speaker layout that suits your
speakers and usage environment. You can check the connection method and default settings.
Yes No
Use height speakers?
When using 1 set of Height Speakers
• 5.1.2 Channel System ( p61)
• 5.1.2 Channel System + ZONE SPEAKER (
p62, 63)
• 5.1.2 Channel System + SPEAKER B ( p64)
• 5.1.2 Channel System (Bi-Amping the Speakers) ( p65)
• 7.1.2 Channel System ( p66)
• 7.1.2 Channel System + ZONE SPEAKER (
p67)
• 7.1.2 Channel System + SPEAKER B (
p68)
• 7.1.2 Channel System (Bi-Amping the Speakers) ( p69)
When using 2 sets of Height Speakers
• 5.1.4 Channel System ( p70)
• 5.1.4 Channel System + ZONE SPEAKER ( p71)
• 5.1.4 Channel System (Bi-Amping the Speakers)
( p72)
• 7.1.4 Channel System ( p73)
• 5.1 Channel System ( p48)
• 5.1 Channel System + ZONE SPEAKER ( p49)
• 5.1 Channel System + SPEAKER B ( p50)
• 5.1 Channel System + SPEAKER B (Bi-Amping the
Speakers) ( p51)
• 5.1 Channel System (Bi-Amping the Speakers) ( p52)
• 5.1 Channel System (Bi-Amping the Speakers) + ZONE
SPEAKER ( p53)
• 7.1 Channel System ( p54)
• 7.1 Channel System + ZONE SPEAKER ( p55, 56)
• 7.1 Channel System + SPEAKER B ( p57)
• 7.1 Channel System + SPEAKER B (Bi-Amping the
Speakers) ( p58)
• 7.1 Channel System (Bi-Amping the Speakers) ( p59)
• 7.1 Channel System (Bi-Amping the Speakers) + ZONE
SPEAKER ( p60)
