Advanced EQ Setup
Reverberation characteristics are automatically calibrated according to the
settings made. After making the following settings, place the speaker setup
microphone in the listening position, and connect to the SETUP MIC jack on the
main unit. Press ENTER and follow the on screen instructions.
Setting Item Default Value Setting Details
Time Position 30 - 50 msec Specify the calibrated time position in the range
between "0 - 20 msec" and "60 - 80 msec" (10
msec intervals).
If the reverberation characteristics differ for each
frequency or each channel in the Reverb View
graph, we recommend selecting "30 - 50 msec". If
the overall reverberation characteristics are similar,
we recommend selecting "60 - 80 msec".
EQ Type Symmetry Select the calibration type.
"Symmetry": Speakers that make one set as a left
and right pair have their frequency characteristics
calibrated atly. Speakers not in pairs, such as
the center speaker, are adjusted individually.
Select when you want to give weight to phase
characteristics for calibration.
"All Channel Adjust": Flatly calibrates individually
the frequency characteristics of all speakers.
Select when you want to give weight to frequency
characteristics for calibration.
"Front Align": Calibrates speakers other than
the front speakers so their characteristics match
those of the front speakers (front speakers are not
calibrated). Select when you want to give weight to
characteristics of the front speakers for calibration.
Standing Wave
Multi Position
No When you select "2” to “9", standing wave
calibration can be performed at multiple listening
positions along with the main listening position. If
there is only one listening position, select "No".
•
If you select "2” to “9”, calibration is rst performed
for the locations other than the main position, then
the main position is calibrated last.
Precision Distance
With the distance of the front left speaker from the listening position as the
standard, adjust the position of each speaker with a precision up to the closest
1 cm. Adjust the distance in order starting at the front right speaker. Test tone
output alternates between the selected speaker and the speaker that is used as
its benchmark. First setup the speaker setup microphone in the listening position
and connect it to the SETUP MIC jack on the main unit, then select this setting.
Setting Item Default Value Setting Details
Front Right
- Move the speakers back and forth about a
centimeter at a time in relation to the speaker setup
microphone so that "Score" becomes "10.0". If the
number does not become "10.0", put the speaker in
the position where the maximum value is achieved.
• Do not move the front left speaker, upon which
calibration is based, during the adjustments.
Center - Move the speakers back and forth about a
centimeter at a time in relation to the speaker setup
microphone so that "Score" becomes "10.0". If the
number does not become "10.0", put the speaker in
the position where the maximum value is achieved.
• Do not move the front left speaker, upon which
calibration is based, during the adjustments.
Height 1 Left - Move the speakers back and forth about a
centimeter at a time in relation to the speaker setup
microphone so that "Score" becomes "10.0". If the
number does not become "10.0", put the speaker in
the position where the maximum value is achieved.
• Do not move the front left speaker, upon which
calibration is based, during the adjustments.
Height 1 Right - Move the speakers back and forth about a
centimeter at a time in relation to the speaker setup
microphone so that "Score" becomes "10.0". If the
number does not become "10.0", put the speaker in
the position where the maximum value is achieved.
• Do not move the height 1 left speaker,
upon which calibration is based, during the
adjustments.
To Next Page
