2
9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
2.31
3. Shorten or lengthen the tie rod until alignment is as
required to achieve the proper toe setting as specified
in “Wheel Toe Alignment”.
IMPORTANT
When tightening the tie rod end jam nuts, the rod ends
must be held parallel to prevent rod end damage and
premature wear. Damage may not be immediately
apparent if done incorrectly.
4. After alignment is complete, torque jam nuts to
specification.
TORQUE
Tie Rod Jam Nut:
14 ft-lbs (19 Nm)
CAMBER AND CASTER
The camber and caster are non-adjustable.
MAINTENANCE
