9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
10.3
GENERAL INFORMATION
BRAKE SERVICE SPECIFICATIONS
FRONT BRAKE
ITEM
STANDARD SERVICE LIMIT
Front Brake Pad Thickness
0.298 ± .007" / 7.56 ± .178 mm 0.030" (.76 mm)
Front Brake Disc Thickness
0.158" (4.01 mm) 0.140" (3.56mm)
Front Brake Disc Runout
-
0.010" (.254mm)
REAR BRAKE
ITEM
STANDARD SERVICE LIMIT
Rear Brake Pad Thickness
0.298 ± .007"/ 7.56 ± .178 mm 0.030" (.76 mm)
Rear Brake Disc Thickness
0.188" (4.78 mm) 0.170" (4.32 mm)
Rear Brake Disc Runout
-
0.010" (.254 mm)
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
2870975
Mity Vac™ Pressure Test
Tool
Bosch Automotive Service Solutions: 1-800-345-2233
or http://polaris.service-solutions.com
