3
9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
3.5
GENERAL ENGINE INFORMATION
GENERAL INFORMATION
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
PW-47053
Bench Mount Engine Stand Adapter
PU-50658 Clutch Center Distance Tool
PU-50784 Crankshaft Removal / Installation Tool Kit
PU-50563
Cylinder Holding & Camshaft Timing Plate
PU-50624
Engine Stand (2” Bore)
PU-50824
Engine Stand Adapter (Mounts To The Engine)
PU-50625
Engine Stand Sleeve Adapter (Use With 2” Bore Stand)
PW-47054
Engine Stand Sleeve Adapter (Use With 2.375” Bore Stand)
PA-49316
Flywheel Puller
PU-50105 Oil Filter Wrench
PV-43531
Oil Pressure Gauge
PU-50569
Oil Pressure Gauge Adapter (2017 and earlier models)
PU-52502
Oil Pressure Gauge Adapter (2018 and later models)
PA-49317 Stator Cover Removal Handles
PV-1253
Valve Spring Compressor
PV-43513-A
Valve Spring Compressor Adapter
PU-50689
Water Pump Mechanical / Oil Seal Installation Kit
Bosch Automotive Service Solutions: 1-800-345-2233 http://polaris.service-solutions.com/.
ENGINE LUBRICATION SPECIFICATIONS
FLUID CAPACITY
Oil Capacity
Approx. 2 Quarts (1.9 L)
Oil Filter Wrench
PU-50105 or 2.5″ (64 mm)
Oil Type
Polaris PS-4 Synthetic Engine Oil
Oil Pressure Minimum Specification
(using Polaris PS-4 at operating temperature)
10 PSI @ 1200 RPM (Minimum)
40 PSI @ 7000 RPM (Minimum)
ENGINE / COOLING SYSTEM
