9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
3.47
IMPORTANT
Orient cir-clip as shown below. The gap should be located at the 6 o’clock or 12 o’clock locations.
IMPORTANT
Orient Piston as shown. Arrow should be pointing to the exhaust valve side.
IMPORTANT
Time balance shaft and crankshaft gears as shown.
