8.22
9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
REF.
PART DESCRIPTION NOTES
q
ASM., GEARCASE, RH, ADC, 4WDC [INCL.
ALL]
w
ASM., COVER, OUTPUT
e
ASM., OUTPUT HUB
r
KIT, FASTENERS 8 ft-lbs (11 Nm)
t
KIT, SEAL REPAIR
y
PLATE, ARMATURE
u
PLATE, ARMATURE, BD
i
BEARING
o
KIT, ROLLER [SET OF 20]
a
ASM., ROLL CAGE [INCL. CAGE, 20 CLIPS]
s
ASM., GEARCASE
d
ASM., PLUG, DRAIN 11 ft-lbs (15 Nm)
f
PLUG, OIL FILL 8-10 ft-lbs (11-14 Nm)
g
RING, RETAINING, INTERNAL
h
KIT, SPRING
j
RING, RETAINING, EXTERNAL
k
ASM., GEAR HOUSING AND PINION GEAR
FINAL DRIVE
