5 – Managing Ports
Displaying Port Information
5-4 59097-02 B
S
5.1.1.4
Displaying Transceiver Media Status
To display transceiver media status, open the View menu and select View Port
Media. Table 5-4 lists the port media states and their meanings.
.
Table 5-4. Port Transceiver Media View
Media Icon Description
Optical SFP, Online (Green)
Optical SFP, Offline (Gray)
Copper SFP, Online (Green)
Copper SFP, Offline (Gray)
XPAK Interface, Online (Green)
XPAK Interface, Offline (Gray)
None Empty port, no transceiver installed
