5 – Managing Ports
Displaying Port Information
5-8 59097-02 B
S
5.1.3
Port Information Data Window
The Port Information data window displays detail information for the selected port.
To open the Port Information data window, click the Port Info tab below the data
window in the faceplate display.
Table 5-6. Port Information Data Window Entries
Entry Description
Port Address Port Fibre Channel address.
Administrative Port Type The administrative port type (G, GL, F, FL,
or Donor). This value is persistent; it will
be maintained during a switch reset. Dur-
ing port auto-configuration, it will be used
to determine which operational port states
are allowed.
Operational Port Type The port type that is currently active. This
will be set during port auto-configuration
based on the administrative port type.
Administrative Port State The port state (Online, Offline, Diagnos-
tics, or Down) which has been set by the
user. This state may be different from the
configured administrative state if the user
has not saved it in the switch configura-
tion. This state is used at the time it is set
to try to set the port operational state. This
value is not persistent and will be lost on a
switch reset.
Operational Port State The port state that is currently active. This
value may be different from the adminis-
trative port state, for example due to an
error condition.
Configured Administrative Port State The port state (Online, Offline, Diagnos-
tics, or Down) which is saved in the switch
configuration, either by the user or at the
factory. This value is persistent; it will be
maintained during a switch reset, and will
be used after a reset to set the port opera-
tional state.
Logged In Indicates whether logged in or not.
E Port Connection Status E_Port connection status. Status can be
None, Connecting, Connected or Isolated.
