Rain Bird LXME2 User Manual

Current Section: Flow Sensor 68 Navigation:
13.1.14 Set Up and Congure High Flow and Low Flow
FLOW SENSOR
Next
Flow Sensors
Set Flow Rates
Set FloManager
Set FloWatch
Current Flow Reading
Set Flow Units
FloWatch
Next
FloWatch On/Off
Set Flow Limits
Set Flow Actions
1 Turn the controller dial to Flow Sensor
2 At the FLOW SENSOR screen, press the key to select “Set FloWatch”, then press Next .
3 At the FloWatch screen, press the
key to select “Set Flow Limits”, then press Next .
4 At the High Flow Settings screen, press the
and keys to set the desired High Flow
Threshold percentage (Max. 200%). Then press the
key.
5 Press the and keys to set the desired High Flow settling time (Up to 10 minutes ),
then press Next .
•
Press and HOLD keys to accelerate settings.
High Flow Settings
Next
High Flow
Threshold
120%
Settling
Time
03Mins
Low Flow Settings
Next
High Flow
Threshold
070%
Settling
Time
03Mins
6 At the Low Flow Settings screen, press the and keys to set the desired Low Flow
Threshold percentage (Max. 95%). Then press the key.
7 Press the and keys to set the desired Low Flow settling time (Up to 10 minutes ).
•
Press and HOLD keys to accelerate settings.
