WARNING
Electric shock can cause severe injury or death. Make sure power supply is turned OFF before connecting power wires.
All electrical connections and wiring runs must be made according to local building codes.
1 Locate the transformer wiring compartment in the lower left corner of the controller
cabinet. Remove the screw on the right-hand side and pull the cover o to expose the
wiring compartment.
17.4.1 Install base and station module (BCM or PSM)
1 Install Base Module (BM2-LXME) or ProSmart module (PSM-LXME2) in Slot 0.
CAUTION:
Be careful not to bend the pins in the sockets when installing the module.
•
The Base and Flow Smart Module include a jumper wire connecting the weather sensor (SEN) terminals. Do
not remove the jumper wire unless you install a weather sensor.
2 Orient the connector on the bottom of the module with the connection socket in Slot 0
on the controller backplane.
3 Carefully fasten the module onto the controller backplane, pressing rmly until it
snaps into place. The red light on the module will ash on and o once if the module is
installed correctly. If the light does not ash once, verify the module is seated correctly.
•
To remove the module, press in on the (two) release buttons on either side of the module.
17.4.2 Install Station Module
Install a 12 station module in Slot 1 that was included with your LXME2 controller. Additional station
modules can be purchased separately.
•
The LXME2 is only compatible with 12 station modules (ESPLXM-SM12) and will not work with 8 or 4 station
modules.
CAUTION:
Be careful not to bend the pins in the sockets when installing the module.
1 Orient the connector on the bottom of the station module with the connection socket
in Slot 1 on the controller backplane.
2 Carefully fasten the module onto the controller backplane, pressing rmly until it
snaps into place. The red light on the module will ash on and o once if the module is
installed correctly. If the light does not ash once, verify the module is seated correctly.
