9.1Languageselection

Thesystemcanoperateinthefollowinglanguages:

English(US)English(UK)

Arabic

Bulgarian

ChineseCroatian

Czech

DanishDutch

FinnishFrench

German

Greek

HebrewIcelandic

ItalianJapaneseKorean

NorwegianPolishPortuguese

(Brazilian)

Russian

SlovenianSpanish

Swedish

Turkish

WiththeHomescreendisplayed:

1.SelectCustomize.

2.SelectLanguage.

3.Selectyourlanguagefromthelistoflanguages.

LanguageispartoftheSharedPreferencesscheme.

OnceanewlanguageisselectedtheUserinterface

languagewillchangeonallMFDsnetworkedusing

SeaTalk

orSeaTalk

andanyinstrumentdisplays

networkedusingSeaTalk

130aSeries/cSeries/eSeries
