Fuse/BreakersItisrecommendedthatyout
athermalbreakerorfuseat
thedistributionpanel.
Thesuitablefuserating
forthethermalbreakeris
dependentonthenumberof
devicesyouareconnecting.If
indoubtconsultanauthorized
Raymarinedealer
PowerconsumptionFullbrightness:
•a75—7.7WMax
•a77—13.2WMax
•a78—9.9WMax
PowerSavemode:
•a75—3.1WMax
•a77—8.2WMax
•a78—5.2WMax
Note:Power
consumptiongures
representaloaded
system;forsonarvariants
thisincludesanactive
600Wtransducerand
DownVision
™
variants
includesanactiveCPT-100
transducer.
LEN(RefertoSeatalk
ng
referencemanualforfurther
information).
1
a9xPowerspecication
Nominalsupplyvoltage
12V/24Vdc
Operatingvoltagerange
10.8Vdcto31.2Vdc
In-lineFuse
•7A(Standard20mmglass
fuse)
PowerconsumptionFullbrightness:
•a95—13.8WMax
•a97—15.1WMax
•a98—15WMax
PowerSavemode:
•a95—5.0WMax
•a97—7.3WMax
•a98—5.7WMax
LEN(RefertoSeatalk
ng
referencemanualforfurther
information).
1
Note:Powerconsumptionguresrepresenta
loadedsystem;forsonarvariantsthisincludes
anactive600WtransducerandDownVision
™
variantsincludesanactiveCPT-100transducer.
a12xPowerspecication
Nominalsupplyvoltage
12V/24Vdc
Operatingvoltagerange
10.8Vdcto31.2Vdc
In-lineFuse
•7A(Standard20mmglass
fuse)
PowerconsumptionFullbrightness:
•a125—23WMax
•a127—23.9WMax
•a128—24.3WMax
PowerSavemode:
•a125—5.2WMax
•a127—7.4WMax
•a128—6.7WMax
LEN(RefertoSeatalk
ng
referencemanualforfurther
information).
1
Note:Powerconsumptionguresrepresenta
loadedsystem;forsonarvariantsthisincludes
anactive600WtransducerandDownVision
™
variantsincludesanactiveCPT-100transducer.
Environmentalspecication
Environmentalspecicationsbelowapplytoall
displayvariants
Operatingtemperature-25ºCto+55ºC(-13ºFto
131ºF)
Storagetemperature-30ºCto+70ºC(-22ºFto
158ºF)
Relativehumidity
Maximum75%
Waterproofrating
•IPX6andIPX7
•IPX6(e165only)
Viewingangle
000
000
000
000
000
00000
00000
00000
D
12576-1
C
D
A
B
a6x
a7x
a9xa12x
A
(Right)
60º75º80º80º
B(Left)60º75º80º80º
C(Up)60º70º80º80º
D
(Down)
50º75º80º80º
Technicalspecication
425
