33.4Networkcableconnectortypes

Thereare2typesofnetworkcableconnector—SeaTalk

andRayNet.

SeaTalk

connector—usedfor

connectingSeaTalk

devicesto

aRaymarinenetworkswitchvia

SeaTalk

cables.

RayNetconnector—usedfor

connectingRaymarinenetwork

switchesandSeaTalk

devicesto

themultifunctiondisplayviaRayNet

cables.Alsorequiredforconnectinga

crossovercouplerifonlyonedevice

isbeingconnectedtothedisplay's

Networkconnector.

440aSeries/cSeries/eSeries
