25.2Mediasources

Thelayoutandcontrolsavailablearedeterminedby

theselectedmediasource.

iPod

D12748-1

5 6

1Albumartwork.

2Tracktitle.

3Artist.

4Trackprogress.

Tracknumber.

6Albumtitle.

MenuoptionsavailableforiPodsareasfollows:

•Browsemusic.

•Repeat.

•Shufe.

•ToneControls.

•SelectFusionSystem.

USB

D12749-1

1Tracktitle.

2Artist.

3Albumtitle.

4Tracknumber.

Trackprogress.

MenuoptionsavailableforUSBdevicesareas

follows:

•Browsemusic.

•Repeat.

•Shufe.

•ToneControls.

•SelectFusionSystem.

DVD

D12750-1

1Timeelapsed.

2Title.

Chapter.

4Remotebutton.

DVDremotecontrolsincluding:

•Directionalkeypad.

•Enter.

•Menu.

•Details.

MenuoptionsavailableforDVDdevicesareas

follows:

•ToneControls.

•SelectFusionSystem.

AM/FMradio

D12751-1

1Frequency.

2Frequencytype.

Channelname.

4Presetname.

MenuoptionsavailablefortheRadioareasfollows:

•Preset.

Fusionlinkapplication

377
