31.1aSeries
a6xPhysicalspecications
Dimensions
•Width:163.57mm(6.44
in)
•Height(NOTincluding
bracket):143.47mm(5.65
in)
•Height(includingbracket):
162.72mm(6.41in)
•Depth(NOTincluding
cables):74.1mm
•Depth(includingcables):
167.5mm(6.6in)
Weight(bareunit)0.715kg(1.58lbs)
a7xPhysicalspecications
Dimensions
•Width:205.1mm(8in)
•Height(NOTincludingbracket):
147.1mm(5.8in)
•Height(includingbracket):163.3
mm(6.4in)
•Depth(NOTincludingcables):73.6
mm(2.9in)
•Depth(includingcables):164.5mm
(6.48in)
Weight(bareunit)0.715kg(1.58lbs)
a9xPhysicalspecications
Dimensions
•Width:250.1mm(9.8in.)
•Height(NOTincluding
bracket):189.5mm(7.5
in.)
•Height(includingbracket):
198.26mm(7.8in.)
•Depth(NOTincluding
cables):82.6mm(3.3in.)
•Depth(includingcables):
164.5mm(6.5in.)
Weight(bareunit)2.31kg(5lbs)
a12xPhysicalspecications
Dimensions
•Width:318mm(12.5in.)
•Height(NOTincluding
bracket):238.3mm(9.4
in.)
•Height(includingbracket):
248.14mm(9.8in.)
•Depth(NOTincluding
cables):84.1mm(3.3in.)
•Depth(includingcables):
164.5mm(6.5in.)
Weight(bareunit)3.68kg(8.1lbs)
a6xPowerspecication
Nominalsupplyvoltage12Vdc
Operatingvoltagerange
10.8Vdcto15.6Vdc
Fuse/BreakersItisrecommendedthatyout
athermalbreakerorfuseat
thedistributionpanel.
Thesuitablefuserating
forthethermalbreakeris
dependentonthenumberof
devicesyouareconnecting.If
indoubtconsultanauthorized
Raymarinedealer
PowerconsumptionFullbrightness:
•a65—8.6WMax
•a67—12.2WMax
•a68—8.5WMax
PowerSavemode:
•a65—3.8WMax
•a67—7.4WMax
•a68—4.9WMax
Note:Power
consumptiongures
representaloaded
system;forsonarvariants
thisincludesanactive
600Wtransducerand
DownVision
™
variants
includesanactiveCPT-100
transducer.
LEN(RefertoSeatalk
ng
referencemanualforfurther
information).
1
a7xPowerspecication
Nominalsupplyvoltage12Vdc
Operatingvoltagerange
10.8Vdcto15.6Vdc
424
aSeries/cSeries/eSeries
