20.6Engineidentication

EnginedatacanbedisplayedonyourMFDusing

theDataapplication,whichprovidessomepreset

Enginepagesfordisplayingsomeofthemost

commontypesofenginedata.

Important:BeforeyoucandisplayEnginedata

onyourMFD,youmust:

•EnsurethatyourMFDisrunningLightHouse

softwareversion8orlater.

•Refertotheimportant“Enginesetupwith

anECIinterface”and“Usingtheengine

identicationwizard”information.

•Makethedataconnections,accordingto

theinstructionsprovidedinthe87202ECI

Installationinstructions.

•Ensurealldatabusesarepoweredup(including

enginedataCANbuses,gateways,andalsothe

SeaTalk

bus).

•Starttheengine.Itisimportantthatonlyone

engineisrunningatatime,toensurethatthe

systemcanisolatethecorrectenginedata

message.

•RuntheEngineidenticationwizardtoensure

thatyourenginesaredisplayedinthecorrect

orderintheDataapplication.
