Dualrangelimitations:
•DualrangecannotbeenabledwhenR
adartargetsarebeingtracked(clearthetargetlistand
tryagain).
•WhenDualrangeisenabledRadartargettrackingisdisabled.
•WhenDualrangeisenabledAutomaticRadartargetacquisitionisdisabled.
•InDualrangethemaximumrotationspeedis24rpm.
•WhenusingaSuperHDRadar
Antennaboostand P
owerboostcontrolsareonlyappliedtothe
Longrangechannel.OpenArrayRadarscannersrunningversion1.xxor2.xxsoftwarewillhave
theShortrangechannel’smaximumrangerestrictedto3nm.
•WhenDualrangeisenabledonaRadarscannerrunningversion1.xxor2.xxsoftwarethe
Expansioncontrolwillbedisabled.
TimedR adartransmission
TohelpconservepoweryoucanconfigureyourRadartoonlytransmitperiodically.
FromtheRadarmenu:
1.Selectthe
Settingsicon.
Thesettingspageisdisplayed.
2.S
witchon
TimeTransmit:usingthetoggleswitch.
3.Select
Standby:andchooseatimeinterval.
4.Select Transmit:andchoosethenumberofrotationsyouwanttheRadartoperform.
TheRadarwilltransmitforthespecifiednumberofrotationsandthenwillswitchtoStandbyforthe
specifiedtimeinterval,thesequencewillrepeatuntilTimedTransmitisswitchedoff.
TheTimedtransmitwillreverttoOffafterapowercycle.
Settingopenarrayantennasize
WhenconnectedtoanOpenArrayRadarScanneryoucanconfigurethe Antennasize.Settingthe
antennasizecanhelpwhensettingaParkingoffset.
FromtheRadarapp:
1.Select
Menu>Settings>Transmission.
2.SelectthecorrectsizeforyourRadar’santennafromthe Antennasizeoption.
Bearingalignment
TheRadarbearingalignmentensuresthatRadarobjectsappearatthecorrectbearingrelativeto
yourvessel’sbow.Youshouldcheckthebearingalignmentforanynewinstallation.
Checkingalignment
Withyourvesselunderway:Alignthebowwithastationaryobjectbetween1&2NMaway.
NotethepositionoftheobjectontheRadarscreen.Ifthetargetisnotundertheshipsheading
marker(SHM),thenbearingalignmentadjustmentisrequired.
Adjustingalignment
Adjustthe BearingalignmentsettinguntilthetargetobjectappearsundertheSHM.
Bearingalignmentsettingcanbeaccessedfromthe Installationtab: Menu>Installation>Bearing
alignment.
R adarapplication
117
