Raymarine axiom pro 9 S User Manual

R
ayNettoRJ45adaptercables
DescriptionTypicaluseQuantity
1AdaptercablewithaR ayNet
(female)socketonone
end,andawaterproof
(female)socketonthe
otherendacceptingthe
followingcableswithan
RJ45SeaTalk
hs
waterproof
locking(male)plug:
•A62245(1.5m).
•A62246(15m).
Atypicaluseforthisadaptercableisto
connectaDSM300sonarmoduletoa
LightHouseMFD,usingall-waterproofcable
connections.Thisadaptercablewillalso
acceptthefollowingRJ45SeaTalk
hs
cables,
althoughtheRJ45plugthatconnectsatthe
equipmentend(e.g.DSM300)willNOTbe
waterproof:
•E55049(1.5m).
•E55050(5m).
•E55051(10m).
•A62135(15m).
•E55052(20m).
1
2
AdaptercablewithaR ayNet
(female)socketononeend,
andawaterproof(female)
RJ45socketontheother
end,alongwithalocking
glandforawatertightfit.
DirectlyconnectaRaymarineradarscanner
withanRJ45SeaTalk
hs
(male)cableto
aRayNetnetworkswitch(e.g.HS5)or
LightHouseMFD.
1
3
AdaptercablewithaR ayNet
(male)plugononeend,
andanRJ45SeaTalk
hs
waterproof(male)plugon
theotherend.
ConnectalegacyG-SeriesGPM-400,C-Series
WidescreenorE-SeriesWidescreenMFDto
aRaymarineradarscannersuppliedwitha
RayNetpower/datacable.
1
Sparesandaccessories
81
