4.5T
ransducerconnection
IfyourMFDincludesabuilt-insonarmodulethenyoucanconnectatransducertoyourMFD.
•AxiomProR VX:
–1x25pinconnector—connecttoRealVision™3Dtransducers
–1x11pinconnector—connectto1kWtransducers.
•AxiomProS
–1x25pinconnector—connecttotransduceradaptorcableA80490,theadaptorcablethen
connectstoaCPT-Sseriestransducer.
Note:
1.OnlyCPT-SseriestransducerscanbeconnectedtoAxiomProSvariantMFDs.
2.T
ransducerextensioncablesareavailable.
3.Adaptorcablesarealsoavailablethatenableconnectionofdifferenttransducers.Referto
Chapter9Sparesandaccessoriesforalistofavailableadaptorcables.
R ealVision™3Dtransducerextensioncable
Forbestperformance,cablerunsshouldbekepttoaminimum.However,forsomeinstallationsit
maybenecessarytoextendthetransducercable.
•3m(9.8ft),5m(16.4ft),and8m(26.2ft)transducerextensioncablesareavailable(partnumbers:
3m-A80475,5m-A80476,8m-A80477).
•Itisrecommendedthatamaximumoftwocableextensionsareused,withthetotalcablelength
notexceeding18m.
Axiomtransduceradaptorcables
Thefollowingadaptorcableareavailabletoenableconnectionofawiderselectionoftransducers.
AxiomDVadaptorcables
A 80484
AxiomDVto7-pinEmbeddedTransducerAdapter
A 80485AxiomDVto7-pinCP370TransducerAdapter
A 80486AxiomDVto9-pinDV&7-PinEmbeddedTransducersY-Cable
A 80487AxiomDVto9-pinDV&7-PinCP370TransducersY-Cable
AxiomR Vadaptorcables
A 80488
AxiomRVto7-pinEmbeddedTransducerAdapter
A 80489AxiomRVto7-pinCP370TransducerAdapter
44
