Direct Printing from a Digital Camera (PictBridge)
120
4
PictBridge Printing
Follow the procedure below to start PictBridge printing on this printer.
Important
❒ Do not disconnect the USB cable while data is being sent. If you do, printing
will fail.
❒ The USB host interface board is supplied with a USB cable and a hook onto
which you can roll up and hang the cable.
A Attach the hook on the back of the printer near the USB connection slot.
Attach the hook where it will not interfere with printer operation and access.
B Check the printer and the digital camera are both switched on.
C Connect a USB cable between the optional USB host interface board in-
stalled on the printer and the digital camera.
The Data In indicator on the printer blinks for several seconds and “PctBrdg”
is displayed on the printer. This indicates the printer recognizes the digital
camera as a PictBridge device.
AQC050S
AQC063S
To Next Page
