Ricoh AficioSP C410DN User Manual

Using NetWare
263
7
E Confirm the settings, and then click [OK].
Configuration is now complete. Wait several minutes before restarting Web
Image Monitor.
F Click [Logout].
Setting Up as a Remote Printer (NetWare 4.x, 5/5.1, 6/6.5)
Follow the procedure below to use the printer as a remote printer under Net-
Ware 4.x, 5/5.1 and 6.
Important
❒ To use the printer as a remote printer under NetWare 4.x/5/5.1, set it to NDS
mode.
❒ Do not use the printer as a remote printer when Pure IP is used.
Setting up using NWadmin
A From Windows, start NWadmin.
For details about NWadmin, see the NetWare manuals.
B Set up the network connection to a print queue. Select the object in which
the print queue is located in the directory tree, and then click [Create] on the
[Object] menu.
C In the [Class of new object] box, click [Print Queue], and then click [OK].
D In the [Print Queue Name] box, enter the name of the print queue.
E In the [Print Queue Volume] box, click [Browse].
F In the [Available objects] box, click the volume in which the print queue is
created, and then click [OK].
G Check the settings, and then click [Create].
H Set up the network connection to a printer. Select the object in which the
printer is located, and then click [Create] on the [Object] menu.
I In the [Class of new object] box, click [Printer], and then click [OK]. For Net-
Ware 5, click [Printer (Non NDPS)].
J In the [Printer name] box, enter the printer name
K Select the [Define additional properties] check box, and then click [Create].
L Assign print queues to the created printer. Click [Assignments], and then
click [Add] in the [Assignments] area.
M In the [Available objects] box, click the queue you created, and then click [OK].
