16
1
3.
Open the power (DC input) cable
cover and take the cable out.
4. Close the battery/card cover and
slide it back into place.
5. Plug the power cord into an out-
let.
• Be sure to firmly attach cables and plug in
cords.
• When you are not using the camera,
unplug the AC Adapter from the camera
and the power outlet.
• While in use, if you detach the AC Adapter
or unplug it from the outlet, data may be
lost.
If you have already used this camera, make
sure it is turned off before removing the AC
Adapter Battery.
Removing the AC Adapter
When using the AC Adapter, the battery level
indication may not reach the full area.
1. Unplug the power plug from the
outlet.
2. Open the battery/card cover.
The cover slides open in two steps.
First slide the cover toward the face of
the camera, then lift it to expose the bat-
tery compartment.
3. Remove the battery.
4. Close the battery/card cover and
slide it back into place.
To Next Page
