G147 3-36
SM
2.
Inner cover [1] (
x2)
3.
Front registration holder [2] (
x1)
4.
Front registration roller gear [3] (
x1)
5.
Registration roller bushing [4] (spring x 1)
6.
High voltage power supply board [5] (
x3,
x6)
7.
Fl
y
w
heels [6] (
x3)
8.
Right rear cover [7] (
x3)
111
113
