DRIVE LAYOUT
SM 19 G838
Finisher
G838
4.2 DRIVE LAYOUT
1. Tray 1 lift motor
2. Entrance roller
3. Tray 2 lift motor
4. Upper exit roller
5. Tray 1 shift motor
6. Exit guide plate motor
7. Lower exit roller
8. Tray 2 shift motor
9. Exit motor
10. Lower transport motor
11. Pre-stack motor
12. Upper transport motor
13. Punch motor
14. Entrance motor
15. Stack feed-out motor
16. Jogger motor
17. Stapler motor
18. Stapler rotation motor
B352D104.WMF
B352D103.WMF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
