9. Press [#Enter].
<Fuser Exit Motor>
10. Press [#Enter] to switch the component on, then press [#Enter] to switch it off.
Fuser Exit Motor
Fuser Exit Motor
11. Press [Escape], then repeat Steps 8 to 11 to check other items.
12. When you are finished, press [Escape] until you see “2.Engine”, then select
“3.End”.
SP5804 Output Check Table
No. Operation Panel More Detail
1 1stPaperFeedCl. 1st Paper Feed Clutch
2 2ndPaperFeedCl. 2nd Paper Feed Clutch
3 3rdPaperFeedCl. 3rd Paper Feed Clutch Paper Tray Unit
4 4thPaperFeed Cl. 4th Paper Feed Clutch Paper Tray Unit
5 By-pass Feed Cl. By-pass Feed Clutch
6 LCT Paper Feed Cl. LCT Paper Feed Clutch
11 1st. Paper Tray 1st. Paper Tray - Lift Motor
12 2nd. Paper Tray 2nd. Paper Tray - Lift Motor
13 By-pass Pickup By-pass Pick-up Solenoid
14 LCT Pick-up Sol. LCT Pick-up Solenoid
17 Transport Motor1 Transport Motor 1 - Finisher
18 Transport Motor2 Transport Motor 2 - Finisher
19 Exit Motor Exit Motor 1 - Finisher
20 Staple Motor Staple Motor 1 - Finisher
21 Punch Motor Punch Motor 1 - Finisher
To Next Page
