SM 6-41 G147
Detailed
Descriptions
size actuator is broken, or if there is no tray installed, the printer control board recognizes
that the paper tray is not installed.
When the paper size actuator is at the “*” mark, the paper tray can be set up to
accommodate one of a wider range of paper sizes by using a menu setting on the machine’s
operation panel.
Models Paper Size Switch
North America Europe/Asia 1 2 3 4
8
1
/
2
" x 13" Portrait A3 Portrait ON ON OFF ON
A4 Landscape A4 Landscape ON ON ON ON
A4 Portrait A4 Portrait ON OFF ON ON
11" x 17" Portrait A5 Portrait OFF OFF ON ON
8
1
/
2
" x 14" Portrait 8" x 13" Portrait ON OFF OFF OFF
8
1
/
2
" x 11" Portrait 8
1
/
2
" x 11" Portrait ON ON OFF OFF
8
1
/
2
" x 11" Landscape 8
1
/
2
" x 11" Landscape ON OFF ON OFF
* *
ON ON ON OFF
ON: Pushed, OFF: Not Pushed
