G147 3-18 SM
5. Press at
to release the charge roller [D], release the charge roller , press
the drum [E] to the front, and then remove the drum
.
- SP Adjustments -
Charge Roller Bias Adjustment 2001-01
Set to the standard value to
ensure carrier is not attracted
to the drum.
ID Sensor Initial Setting 3001-02 Initializes the ID sensor.
Image Transfer Current – Image Face 2301 01
Image Transfer Current – Image Back 2301 02
Image Transfer Current – Lead Edge Face 2301 03
Image Transfer Current – Image Face
By-pass
2301 04
Set to the default settings.
