Overview
SM 1-5 D117/D118
Product
Information
1.3 OVERVIEW
1.3.1 COMPONENT LAYOUT
1. Toner Bottle [K]
2. Toner Bottle [C]
3. Toner Bottle [M]
4. Toner Bottle [Y]
5. Image Transfer Belt Unit
6. Fusing Unit
7. Duplex Unit
8. Paper Transfer Roller
9. ID Sensor
10. Image Transfer Belt Cleaning Unit
11. PCDU (Photo Conductor and
Development Unit)
12. LDU 2 (for Magenta, Yellow)
Unit
13. Polygon Mirror Motor 2
14. LDU 1 (for Black, Cyan)
15. Polygon Mirror Motor 1
16. Standard Paper Feed Tray (Tray 1)
