Ricoh MP C305SPF User Manual

Overview
SM 1-7 D117/D118
Product
Information
1.3.3 DRIVE LAYOUT
[1]: Scanner Drive Motor
[2]: Development Clutch (Black)
[3]: Drum Drive Motor (Black)
[4]: Drum Drive Motor (Color)
[5]: Development Motor (Color)
[6]: Paper Feed Clutch
[7]: By-pass Tray Bottom Plate Lift Cam Drive Clutch
[8]: Paper Transport Motor
[9]: By-pass Feed Clutch
[10]: Duplex Transport Clutch
[11]: Registration Clutch
[12]: Fusing Drive Motor

Ricoh MP C305SPF Specifications

General

Brand	Ricoh
Model	MP C305SPF
Category	All in One Printer
Language	English
