ELECTRICAL COMPONENTS
SM 6-3 J001/J003
Detailed
Descriptions
6.2 ELECTRICAL COMPONENTS
1. Horizontal Motor 10. Waste Ink Full Sensor
2. PSU 11. Tank Full Sensor
3. Trailing Edge Sensor 12. Operation Panel
4. Bypass Set Sensor 13. Air Release SOL
5. Temperature/Humidity Sensor 14. DC Relay Board
6. Control Board 15. Vertical Motor
7. Duplex Set SW 16. Feed Clutch
8. Maintenance Motor 17. Horizontal Encoder
9. Maintenance Unit HP Sensor
G707D904.WMF
11
1213
14
15
16
17
2
3
4
6
7
8
9
10
1
5
