INSTALLATION PROCEDURE
SM 1-15 J001/J003
Installation
5. Get a stack of paper. Then fan it to remove static cling.
6. Load the paper [A] into the cassette.
7. Add paper until it gets to the load limit marks [B].
Important: Never load paper higher than the load limit mark.
8. Pinch the bottom fence tabs [C]. Then move the bottom fence to the edge of
the stack.
9. Check the positions of the side fences.
• The width side fences and bottom fence should not be to tight against the
sides and bottom of the stack.
• If the stack goes upward, the fences are too tight. Adjust their positions so
the top of the stack is perfectly flat.
[A]
[B]
[C]
