Chapter 6 MATH and Measurements RIGOL
MSO2000A/DS2000A User’s Guide 6-17
One-key Measurement of 29 Parameters
Press MENU at the left of the screen to turn on the measurement menu of the 29
parameters and then press the corresponding menu softkey to quickly realize
“One-key” measurement. The measurement result will be displayed at the bottom of
the screen.
Note: Press Measure Source to select the current measurement source. When
the measurement source is set to any channel of D0-D15, “One-key” measurement
only supports period, frequency, positive pulse width, negative pulse width, positive
duty cycle, negative duty cycle, delay and phase.
The menu item icons and measurement results of time, voltage and area parameters
are always in the same color as the current measurement channel (Measure
Source). The menu item icons and measurement results of delay and phase
parameters are always in white; the numbers in the menu item icons and results
denote source A and source B currently selected (when the signal source is an analog
channel, the color of the number is the same as that of the channel selected; when
the source channel is a digital channel, the number is always in green).
Note: If the measurement result is displayed as “*****”, there is no signal input into
the current measurement source or the measurement result is out of the valid range
(too large or too small).
