RIGOL Chapter 2 To Set the Vertical System
2-4 MSO2000A/DS2000A User’s Guide
Probe Ratio
You can set the probe attenuation ratio manually. The probe ratio values available
are as shown in the table below.
Table 2-1 Probe Attenuation Coefficient
Menu
Attenuation Coefficient
(waveform display amplitude : actual waveform amplitude)
0.01X
0.02X
0.05X
0.1X
0.2X
0.5X
1X
2X
5X
10X
20X
50X
100X
200X
500X
1000X
0.01:1
0.02:1
0.05:1
0.1:1
0.2:1
0.5:1
1:1
2:1
5:1
10:1
20:1
50:1
100:1
200:1
500:1
1000:1
