RIGOL Chapter 5 To Trigger the Oscilloscope
5-8 MSO2000A/DS2000A User’s Guide
Trigger Type
MSO2000A/DS2000A provides various trigger types, including various serial bus
triggers. You can press MENU (in the trigger control area (TRIGGER) at the front
panel)  Type to select the desired trigger type.
 Edge Trigger
 Pulse Trigger
 Runt Trigger
 Windows Trigger (Option)
 Nth Edge Trigger (Option)
 Slope Trigger
 Video Trigger (HDTV Option)
 Pattern Trigger
 Delay Trigger (Option)
 TimeOut Trigger (Option)
 Duration Trigger (Option)
 Setup/Hold Trigger
 RS232 Trigger
 I2C Trigger
 SPI Trigger
 USB Trigger (Option)
 CAN Trigger (Option)
