Chapter 18 Specifications RIGOL
MSO2000A/DS2000A User’s Guide
Chapter 18 Specifications
All the specifications are guaranteed except the parameters marked with “Typical”
and the oscilloscope needs to operate for more than 30 minutes under the specified
operation temperature.
Sample
Sample Mode Real-time Sample
Real Time
Sample Rate
Analog channe: 2 GSa/s (single-channel), 1 Gsa/s
(dual-channel)
Digital channel: 1 GSa/s (max)
Peak Detect
Analog channe: 500 ps (single-channel), 1 ns (dual-channel)
Digital channel: 2 ns
Averaging
After both the channels finish N samples at the same time, N
can be 2, 4, 8, 16, 32, 64, 128, 256, 512, 1024, 2048, 4096 or
8192.
High Resolution
12 bits of resolution when ≥5 μs/div @ 1 GSa/s (or ≥10 μs/div
@ 500 MSa/s).
Min Detect Pulse
Width
Digital channel: 5 ns
Memory Depth
Analog channel:
single-channel: Auto, 14k pts, 140k pts, 1.4M pts, 14M pts and
56M pts (option) are available
dual-channel: Auto, 7k pts, 70k pts, 700k pts, 7M pts and 28M
pts (option) are available
Digital channel: 14M pts maximum
